| Type |
Medium
distance |
Long
distance |
Short
distance |
Medium
distance |
| Model
number |
BGS-V30N/P
BGS-V30CN/P |
BGS-V50N/P
BGS-V50CN/P |
BGS-10N/P
BGS-10CN/P |
BGS-30N/P
BGS-30CN/P |
Detecting
distance |
White
paper |
10-300
mm |
20-550
mm |
0-100
mm |
0-300
mm |
| Gray
paper |
20-300
mm |
30-500
mm |
0-100
mm |
0-300
mm |
| Black
paper |
40-250
mm |
50-400
mm |
0-80
mm |
0-250
mm |
| Light
source |
Red
LED |
| Response
time |
2
ms max. |
| Maximum
repeatability |
Parallel
to detection axis: 1.5mm
Perpendicular to detection axis : 1.5mm |
Parallel
to detection axis: 3.0mm
Perpendicular to detection axis : 2.0mm |
Parallel
to detection axis: 0.3mm
Perpendicular to detection axis : 0.3mm |
Parallel
to detection axis: 1.5mm
Perpendicular to detection axis : 0.5mm |
| Hysteresis |
5%
Max. |
10%
Max. |
3%
Max. |
5%
Max. |
| Sensitivity
adjustment |
2
rotation volume with indicator |
| Indicator |
Red
LED |
| Control
output |
NPN
or PNP open-collector : 100mA (30 VDC) max. |
| Self-diagnostic
function |
- |
| Test
input |
- |
| Operating
mode |
Light-On
(On when light received) / Dark-On (On when no light received)
(Cable connection determines output format.) |
| Cable
and connector |
Cable
type : 3.8-mm dia. X 2m Connector type : 4-pin connector (M12
thread) |
| Insulation
resistance |
20MΩmin.
(500VDC) |
| Supply
voltage |
10-30VDC |
| Current
consumption |
25
mA max. |
| Noise
resistance |
JIS
standard |
C4525:
500 V, 1μs(pulse width ) |
| IEC
standard |
IEC1000-4-2.3.4
LEVEL3 |
| Internal
company standard |
Feline
LEVEL3 |
| Ambient
resistance |
Ambient
temperature/ relative humidity |
-25°C
to 55°C / 35-82% |
| Max.
ambient light |
Sunlight
: 10,000 lux, Incandescent lamp : 3,000 lux |
| Dielectric
strength |
500V |
| Vibration |
10-55
Hz, 1.5-mm amplitude, in X, Y, and Z directions, 2 hours respectively |
| Shock |
Approx.
50 G (500m/s2), in X, Y, and Z directions, 3 times
respectively |
| Protection
Category |
IEC
standard : IP-67 |
| Material |
Casing
: ABS, Front cover : PC |
| Weight
(excluding cable) |
45g |
20g |
| *Specifications
are subject to change without notice. |
